Power Macintosh 7600/120
Photo 1: Stephen Edmonds, CC BY-SA 2.5, via Wikimedia Commons (Pm7600 01.jpg)
Personal computer, 1996, Apple. The Power Macintosh 7600/120 succeeded the 7500 as Apple's mid-range desktop in April 1996, with a PowerPC 604 at 120 MHz on the processor card, the same Outrigger case, PCI slots and built-in video input.
| Years | April 1996 to November 1997 |
|---|---|
| Manufacturer | Apple Computer Inc. (US) |
| Processor | PowerPC 604 at 120 MHz on a removable processor card (132 and 604e 200 MHz versions followed) |
| RAM | 16 MB, expandable to 1 GB (70 ns 168-pin DIMM) |
| ROM | 4 MB |
| VRAM | 2 MB, expandable to 4 MB |
| Built-in storage | 3.5" floppy disk drive (1.4 MB), SCSI hard disk (1.2 GB), 8x CD-ROM drive |
| Interfaces | 2 x SCSI, ADB (Apple Desktop Bus), 2 x GeoPort serial, DB-15 video, Ethernet (AAUI and 10BASE-T), RCA audio input and output, composite and S-Video input |
| Expansion | 3 PCI slots |
| Operating system | System 7.5.3 to Mac OS 9.1 |
| Dimensions | 155 (H) x 366 (W) x 444 (D) mm |
| Weight | 10 kg |
| Price (1996) | US$3,000 |
Documentation
No documents available yet for this model. Browse the documentation section.
